AC 630 (MAX 3KW) Charger
| ltem | Parameter |
| Rated power | MAX 3000W |
| Input | AC 100~240V MAX 15A 47~ 63 Hz |
| Output |
DC 24V100A (5V~30V) DC 48V50A (5V~60V) DC 80V30A (5V~100V) |
| Protocol | CAN |
| Cooling Method | Fan/ IP54 |
| Protection | OVP/UVP /OCP/ SCP/ OTP |
| Efficiency | ≥92% |
| Safety | CE, BIS, UL , CCC |
| Application | NMC / LFP |
| Size | 378*152*97mm |
|
Product features: Small size, fully potted PCB, IP54 waterproof, very cost-effective, aluminum alloy with good heat dissipation, impact resistance, fast charging, supports full voltage, passed CE and BIS Support DC Charging pile It CAN also customize and develop the CAN protocol to meet all your needs Mainly used in: electric forklifts, VGA electric vehicles, Gaul ball cars, electric tricycles, electric motorcycles and other high-power charging equipment |
|
